This guide explains the client tasks required to migrate from Predictive Merchandiser to Commerce Studio in Lucidworks Platform. While Lucidworks will complete the majority of the migration, you will need to perform certain pre-migration and post-migration tasks. The migration is one-way. The migration can be reverted back to Predictive Merchandiser, but any changes made in Commerce Studio are not reverted back into Predictive Merchandiser.

Prepare for the migration

Complete these client tasks before Lucidworks begins the migration.

Determine which rules and rewrites will be migrated

  • Unpublished rules or rewrites have never been published.
  • Staged rules or rewrites have been published at least once, but then were changed and those changes are not yet published. It also includes rules and rewrites that were deleted, but the deletion has not yet been published.

Unpublished rules

If you want unpublished rules migrated, then inform Lucidworks to set excludeUnpublishedRules to false during the migration (this is the default). If you do not want unpublished rules to be migrated, tell Lucidworks to set excludeUnpublishedRules to true.

Unpublished rewrites

If you want unpublished rewrites migrated, then inform Lucidworks to set excludeUnpublishedRewrites to false during the migration (this is the default). If you do not want unpublished rules to be migrated, tell Lucidworks to set excludeUnpublishedRewrites to true.

Staged rules and rewrites

Staged rules and rewrites are skipped in the migration, so you must publish or revert all staged changes to rules and rewrites.You can only view staged changes in Predictive Merchandiser that belong to your user.To check for staged changes that belong to other users in your organization, do the following:
  1. Copy the precheck.sh script below to check for staged (unpublished) rules and rewrites:
#!/bin/bash

set -e

# Function to perform curl requests with error handling and retries
perform_curl_request() {
    local url=$1
    local max_retries=3
    local retry_count=0
    local wait_time=5
    local curl_opts="-s -w '\n%{http_code}' -H 'Accept: application/json' -u '$FUSION_USERNAME:$FUSION_PASSWORD'"

    while [ $retry_count -le $max_retries ]; do
        # Execute curl and capture response with status code
        local response=$(eval "curl $curl_opts '$url'")
        local status_code=$(echo "$response" | tail -n1)
        local body=$(echo "$response" | sed '$d')

        # Check if status code is in 2xx range
        if [[ $status_code =~ ^2[0-9][0-9]$ ]]; then
            echo "$body"
            return 0
        else
            # Report the error
            echo "Error: HTTP request failed with status code $status_code" >&2
            echo "URL: $url" >&2

            # If it's a 4xx error, don't retry
            if [[ $status_code =~ ^4[0-9][0-9]$ ]]; then
                echo "Client error. Not retrying." >&2
                exit 1
            fi

            # For other errors (5xx), retry if we haven't reached max retries
            if [ $retry_count -lt $max_retries ]; then
                retry_count=$((retry_count + 1))
                echo "Retrying in $wait_time seconds... (Attempt $retry_count of $max_retries)" >&2
                sleep $wait_time
            else
                echo "Maximum retries reached. Giving up." >&2
                exit 1
            fi
        fi
    done

    exit 1
}

# Function to validate JSON blob rules
validate_json_blob_rule() {
    local doc="$1"
    local doc_id="$2"

    local json_blob_s=$(echo "$doc" | jq -r '.json_blob_s // empty')
    # Guard: Exit early if no json_blob_s field
    [ -z "$json_blob_s" ] && return 0

    # Decode base64 and validate JSON structure
    local decoded_json=$(echo "$json_blob_s" | base64 -d 2>/dev/null || echo "")
    # Guard: Exit early if decoding failed
    [ -z "$decoded_json" ] && return 0

    # Check if the decoded JSON is valid
    if ! echo "$decoded_json" | jq empty 2>/dev/null; then
        # Invalid JSON in blob
        bad_json_blob_rule_ids+=("$doc_id")
        echo "found JSON blob rule with invalid JSON: $doc_id"

        # Add this entry to our JSON structure for bad JSON blobs
        local content_entry=$(jq -n --arg id "$doc_id" \
                              --argjson content "$doc" \
                              --arg decoded_content "$decoded_json" \
                              '{
                                "id": $id,
                                "ruleContent": $content,
                                "decodedJsonBlob": $decoded_content,
                                "error": "Invalid JSON syntax"
                              }')

        # Add this entry to the second problem (index 1) in our JSON structure
        json_output=$(echo "$json_output" | jq --argjson entry "$content_entry" '.problems[1].content += [$entry]')
        return 0
    fi

    # Valid JSON - now check if it's multiple objects
    # A simple heuristic: if we can't parse it as a single JSON value, it's likely multiple objects
    if echo "$decoded_json" | jq -e 'type' >/dev/null 2>&1; then
        # Guard: Exit early if it's a valid single JSON object
        return 0
    fi

    # This means jq couldn't parse it as a single value, likely multiple objects
    bad_json_blob_rule_ids+=("$doc_id")
    echo "found JSON blob rule with multiple objects: $doc_id"

    # Add this entry to our JSON structure for bad JSON blobs
    local content_entry=$(jq -n --arg id "$doc_id" \
                          --argjson content "$doc" \
                          --arg decoded_content "$decoded_json" \
                          '{
                            "id": $id,
                            "ruleContent": $content,
                            "decodedJsonBlob": $decoded_content
                          }')

    # Add this entry to the second problem (index 1) in our JSON structure
    json_output=$(echo "$json_output" | jq --argjson entry "$content_entry" '.problems[1].content += [$entry]')
}

# Function to check for staged published rules
check_staged_published_rule() {
    local doc="$1"
    local doc_id="$2"
    local deployed="$3"

    # Guard: Exit early if rule is deployed (not staged)
    [ "$deployed" != "false" ] && return 0

    # Check if the doc exists in the live rewrites collection
    local live_url="$FUSION_BASE_URL/api/apps/$FUSION_APP_ID/query-rewrite/search?q=id:$doc_id&isLive=true&doc_type=rule&fl&rows=1&start=0"
    echo "fetching live rule via $live_url"
    local live_response=$(perform_curl_request "$live_url")

    # Check if we have any rules in the live response array
    local live_docs_count=$(echo "$live_response" | jq -r '.response.docs | length')

    # Guard: Exit early if doc doesn't exist in live collection
    [ "$live_docs_count" -eq 0 ] && return 0

    # Found a published rule with staged changes
    staged_published_rule_ids+=("$doc_id")
    echo "found published rule with staged changes: $doc_id"

    # Extract the live doc from the response
    local live_doc=$(echo "$live_response" | jq '.response.docs[0]')

    # Create a new entry for this rule with both staging and live content
    local content_entry=$(jq -n --arg id "$doc_id" \
                      --argjson staging "$doc" \
                      --argjson live "$live_doc" \
                      '{
                        "id": $id,
                        "stagingContent": $staging,
                        "liveContent": $live
                      }')

    # Add this entry to our JSON structure
    json_output=$(echo "$json_output" | jq --argjson entry "$content_entry" '.problems[0].content += [$entry]')
}

# Function to display help message
show_help() {
    echo "Usage: $0 <fusion_username> <fusion_password> <fusion_base_url> <fusion_app_id> [output_file]"
    echo "Example: $0 admin password https://fusion.example.com MyFusionApp precheck_results.json"
    echo "This script performs pre-checks for Fusion content before migration."
    echo "Arguments:"
    echo "  fusion_username   Fusion username"
    echo "  fusion_password   Fusion password"
    echo "  fusion_base_url   Base URL of the Fusion instance"
    echo "  fusion_app_id     Application ID of the Fusion app to check"
    echo "  output_file       (Optional) Output file to save results (default: precheck_results.json)"
}

# Check if required arguments are provided
if [ "$#" -lt 4 ]; then
  show_help
  exit 1
fi

FUSION_USERNAME=$1
FUSION_PASSWORD=$2
FUSION_BASE_URL=$3
FUSION_APP_ID=$4
OUTPUT_FILE=${5:-precheck_results.json}

# Input validation
if [ -z "$FUSION_USERNAME" ]; then
  echo "Error: fusion_username is required"
  show_help
  exit 1
fi

if [ -z "$FUSION_PASSWORD" ]; then
  echo "Error: fusion_password is required"
  show_help
  exit 1
fi

if [ -z "$FUSION_BASE_URL" ]; then
  echo "Error: fusion_base_url is required"
  show_help
  exit 1
fi

if [ -z "$FUSION_APP_ID" ]; then
  echo "Error: fusion_app_id ID is required"
  show_help
  exit 1
fi

# Check if jq is installed
if ! command -v jq &> /dev/null; then
    echo "Error: jq command line tool is required but not installed. Please install jq and try again: https://jqlang.org/"
    exit 1
fi

# Check if output file exists
if [ -f "$OUTPUT_FILE" ]; then
    read -p "File $OUTPUT_FILE already exists. Overwrite? (y/n): " -n 1 -r
    echo
    if [[ ! $REPLY =~ ^[Yy]$ ]]; then
        echo "Operation cancelled."
        exit 1
    fi
fi

# Ensure the output file is writeable
if ! touch "$OUTPUT_FILE" &> /dev/null; then
    echo "Error: Output file $OUTPUT_FILE is not writeable. Check output path / permissions and try again."
    exit 1
fi

# Initialize JSON structure
json_output='{
  "problems": [
    {
      "problem": "Published rule with staged changes will be skipped during migration",
      "fix": "Publish or revert the changes, or manually re-create the skipped content after migrating",
      "content": []
    },
    {
      "problem": "JSON blob rule contains multiple JSON objects instead of a single object",
      "fix": "Update the JSON blob rule to contain only a single JSON object at the top level",
      "content": []
    }
  ]
}'

# Initialize array to store staged published rule IDs
declare -a staged_published_rule_ids

# Initialize array to store bad JSON blob rule IDs
declare -a bad_json_blob_rule_ids

# Fetch query rewrite instances with pagination
start=0
rows=10
processed_docs=0

while true; do
    page_url="$FUSION_BASE_URL/api/apps/$FUSION_APP_ID/query-rewrite/instances?sort=id+asc&doc_type=rule&rows=$rows&editSessionId=*&start=$start"
    echo "fetching next page of rules via $page_url"
    response=$(perform_curl_request "$page_url")

    # Check if we got an empty array, which means we're done paginating
    array_length=$(echo "$response" | jq -r '. | length')
    if [ "$array_length" -eq 0 ]; then
        break
    fi

    echo "Retrieved $array_length rules at offset $start"

    # Process each doc in the array
    while read -r doc; do
        doc_id=$(echo "$doc" | jq -r '.id')
        deployed=$(echo "$doc" | jq -r '.deployed')
        doc_type=$(echo "$doc" | jq -r '.type // empty')

        # Check for bad JSON blob rules
        if [ "$doc_type" = "json_blob" ]; then
            validate_json_blob_rule "$doc" "$doc_id"
        fi

        # Check for staged published rules
        check_staged_published_rule "$doc" "$doc_id" "$deployed"

        processed_docs=$((processed_docs + 1))
    done < <(echo "$response" | jq -c '.[]')

    # Move to the next page
    start=$((start + rows))
done

# Write the final JSON output to file
echo "$json_output" | jq '.' > "$OUTPUT_FILE"

# Output results
total_staged_issues=0
total_json_blob_issues=0
if [ -n "${staged_published_rule_ids[*]:-}" ]; then
    total_staged_issues=${#staged_published_rule_ids[@]}
fi
if [ -n "${bad_json_blob_rule_ids[*]:-}" ]; then
    total_json_blob_issues=${#bad_json_blob_rule_ids[@]}
fi

total_issues=$((total_staged_issues + total_json_blob_issues))

# Guard: Exit early if no issues found
if [ $total_issues -eq 0 ]; then
    echo "All pre-checks passed. No issues found."
    echo "Processed $processed_docs rules."
    exit 0
fi

# Report issues found
echo "The following pre-checks failed:"

# Report staged published rule issues
if [ $total_staged_issues -gt 0 ]; then
    echo "  Found published rules with staged changes. Publish or revert the changes to fix this issue."

    # Display up to 10 IDs
    display_count=$([ $total_staged_issues -gt 10 ] && echo 10 || echo $total_staged_issues)
    for ((i=0; i<display_count; i++)); do
        echo "  - ${staged_published_rule_ids[$i]}"
    done

    # Indicate if there are more
    [ $total_staged_issues -gt 10 ] && echo "  ... and $((total_staged_issues - 10)) more."
fi

# Report JSON blob rule issues
if [ $total_json_blob_issues -gt 0 ]; then
    echo "  Found JSON blob rules with multiple JSON objects instead of a single object."

    # Display up to 10 IDs
    display_count=$([ $total_json_blob_issues -gt 10 ] && echo 10 || echo $total_json_blob_issues)
    for ((i=0; i<display_count; i++)); do
        echo "  - ${bad_json_blob_rule_ids[$i]}"
    done

    # Indicate if there are more
    [ $total_json_blob_issues -gt 10 ] && echo "  ... and $((total_json_blob_issues - 10)) more."
fi

echo "See $OUTPUT_FILE for the full list of invalid content with complete document details"
echo "Processed $processed_docs rules."
exit 0
  1. Run the script, replacing the placeholder values with your values.
    ./precheck.sh FUSION_USERNAME FUSION_PASSWORD FUSION_BASE_URL FUSION_APP_ID

PlaceholderDescription
FUSION_USERNAMEYour Fusion username.
FUSION_PASSWORDThe password for your Fusion user.
FUSION_BASE_URLThe URL of your Fusion instance including https://. For example, https://FUSION_HOST.com.
FUSION_APP_IDThe application ID of the Fusion app that contains your Predictive Merchandiser. This is the value of the id field, and may or may not match the name of the Fusion app. To obtain the ID, sign in to your Fusion instance. For example, FUSION_INSTANCE.com. Then also open a different browser window and enter https://FUSION_INSTANCE.com/api/apps. The id and name display for each valid Fusion app. The value in the id field is the value that needs to be used in this field.
If you receive an error stating bash: ./precheck.sh: Permission denied: 1. Make the script executable: chmod +x precheck.sh. 2. Run the script again.
  1. Check the output to see if any issues were detected. If there are no issues, the output returns All pre-checks passed. No issues found. Continue to retrieve list of objects in Predictive Merchandiser. If there are issues, the output returns a list of issues like the following:
    The following pre-checks failed:
      Found published rules with staged changes. Publish or revert the changes to fix this issue.
      - 2fRtM1GEsU
      - E1YkUTX9r6
      - Eb2A6WARag
      - FNS7Whciwx
      - LlIsMfK4kq
      - OidpIUrVv3
      - P39TDQ2X1K
      - RYbY2XPMOI
      - ZHvW2LiQpe
      - aCseNzc4Xc
      ... and 6 more.
    See precheck_results.json for the full list of invalid content

  2. Review precheck_results.json and inspect each reported rule. If you created the rules, sign into Predictive Merchandiser and publish or revert the staged changes. If the unpublished rules were created by a different user, you cannot publish or revert the rules in the Predictive Merchandiser UI. There are a few options for resolving unpublished rules owned by another user:
    • After you complete the pre-migration tasks, tell Lucidworks to proceed with the migration. These rules are skipped and you can re-create them in Commerce Studio.
    • Use the Fusion Query Rewrite and Custom Rule APIs to manually publish or revert the unpublished rules.
    • Use the Fusion Query Rewrite and Custom Rule APIs, or Solr, to manually change the edit session ID of the content in Solr to your current user. Then, manually fix the content in the Predictive Merchandiser UI.
    • Have the user that owns the content in Predictive Merchandiser sign in and either publish or revert the changes.
  3. After resolving issues, re-run the script. If there are no issues, continue to retrieve list of objects in Predictive Merchandiser.
You can run the precheck.sh script at any time, even after a migration if desired. It makes no changes to contents and works even if Commerce Studio is enabled.
After preparing Predictive Merchandiser for migration, Lucidworks recommends that you export lists of rules, rewrites, templates, and zones from your Predictive Merchandiser instance to compare against Commerce Studio later. This will help serve as a reference when performing your post-migration validation checks.
  1. Export a list of your rules and rewrites:
    curl --request GET \
      --url  USER:PASSWORD \
      'https://FUSION_HOST/api/apps/APP_NAME/query-rewrite/instances' \
      --header 'accept: application/json' \
      > exported-rules.json

  2. Create an inventory of your rules, noting how many of each type and tag appear in the list.
  3. Export a list of your zones:
    curl --request GET \
    -u USER:PASSWORD \
      --url 'https://FUSION_HOST/api/templating/zones?context=app:APP_NAME' \
      --header 'Accept: application/json' \
      > zones.json

  4. Export a list of your templates:
    curl --request GET \
    -u USER:PASSWORD \
      --url 'https://FUSION_HOST/api/templating/templates?context=app:APP_NAME' \
      --header 'Accept: application/json' \
      > templates.json

Notify Lucidworks to begin the migration, but keep in mind that once the migration begins, you will no longer be able to access Predictive Merchandiser.Lucidworks will set up the Commerce Studio integration and instance, and migrate your data from Predictive Merchandiser to Commerce Studio.
Do not proceed with subsequent procedures until Lucidworks confirms the migration is successful.

Post-migration tasks

Complete these client tasks when Lucidworks notifies you the migration is complete.
Lucidworks will run the validation checks in this section, but you must also validate that all Predictive Merchandiser objects appear in Commerce Studio.Because you can no longer access Predictive Merchandiser, you must consult the exported JSON you generated in Retrieve lists of objects in Predictive Merchandiser for validation checks.
  1. Sign in to Lucidworks Platform as a workspace owner and navigate to Commerce Studio.
  2. Navigate to Rules, then compare your rule count in Commerce Studio against the JSON you exported from Predictive Merchandiser.
  3. Navigate to Rewrite, then validate that your query rewrites in Commerce Studio match the exported JSON.
  4. Navigate to Pages, then validate your templates have become pages in Commerce Studio, and that the count matches the exported JSON.
  5. Open each page, then validate your Predictive Merchandiser zones have become sections in Commerce Studio, and they are associated with the correct page.
  6. Navigate to the Editor and check that rules and rewrites are applied as expected. Some rules and rewrites only fire under specific conditions:
    1. For rules that fire under specific templates, change your page to match the required template.
    2. For rules that fire only when specific tags are applied, verify the tags are displayed on the Rules page for the rule.
  7. Perform additional rules and rewrites validations as needed, using the exported rules JSON as a reference. For example, check that the direction of synonym rewrites matches the expected direction.
If you encounter any issues, contact your Lucidworks representative.Web traffic continues to use rules and rewrites from Predictive Merchandiser. Changes made in Commerce Studio do not affect live traffic. Contact Lucidworks when you complete the validation tasks.

Revert back to Predictive Merchandiser

If you want to revert back to using Predictive Merchandiser, inform Lucidworks. Then Lucidworks must delete the Commerce Studio instance. If the Commerce Studio instance is deleted, changes you made to Commerce Studio after the initial migration from Predictive Merchandiser are not populated back into Predictive Merchandiser. When the Commerce Studio instance is deleted, the system should automatically revert the Fusion app back to Predictive Merchandiser. This restores access to Predictive Merchandiser and routes live traffic back to its rules and rewrites, if traffic had previously been switched to Commerce Studio.

Frequently asked questions

Can I revert back to Predictive Merchandiser after switching to Commerce Studio? Yes. However, any changes made in Commerce Studio after switching will not be reverted back into Predictive Merchandiser. Does switching to Commerce Studio immediately affect live web traffic? No. After a successful migration, web traffic continues to use rules and rewrites from Predictive Merchandiser. What happens if I forget to publish changes in Predictive Merchandiser before migrating? If you fail to publish pending rules and rewrites before starting the migration, the migration may fail or result in incomplete or inaccurate data. All changes must be published before proceeding.

Troubleshooting

This section provides troubleshooting steps for resolving issues with the Commerce Studio Editor when integrated with Fusion. Use this guidance to debug unexpected behavior that may be caused by Fusion query pipeline or query profile configuration. This content is intended for users with experience in Fusion and search engineering.

Symptoms

You may be experiencing a configuration issue if you observe any of the following:
  • No results or facets returned in the Editor
  • Error messages when performing searches
  • Rules not firing or not appearing after creation
  • Rewrites not triggering or not affecting live traffic
  • Mismatch between facets and results list
  • “Targeted documents” column in the rules table is empty or incorrect
  • No field value suggestions when configuring rule conditions
  • Missing stage data in the Ranking Factors UI

General troubleshooting steps

  1. Open your browser’s developer tools and go to the Network tab.
    1. Retry the failing action.
    2. Look for requests with a non-200 status or check render endpoint responses for errorMessage fields.
    3. Use the fusionRequestUrl to replicate the request in Fusion Query Workbench.
  2. Verify that the query pipeline behaves as expected in Fusion Query Workbench.
    1. Confirm there are no errors.
    2. Verify expected results are returned.
    3. In the JSON view, check for fusion.applicable_rules or fusion.tagger values.
  3. Confirm that rules and rewrites are saved to the correct Solr collections.
    1. In Solr Admin, check APP_NAME_query_rewrite_staging_em and APP_NAME_query_rewrite_em.
    2. Use the rule ID to query and confirm the entry exists.
  4. Ensure the staging collection has only one replica.
    1. If multiple replicas exist, set shards.preference=replica.leader in the Apply Rules and Text Tagger stage parameters.
  5. Verify that the pipeline supports the fl parameter.
    1. Do not overwrite fl. Add required fields only when needed.
    2. Do not use fl=*.

Required pipeline configuration

Your Fusion query pipeline must include the following stages in this order:
  1. Text Tagger stage with a blank value in the Tagger Collection field
  2. Apply Rules stage with a blank value in the Collection field
  3. Solr Query stage
  4. Modify Response with Rules stage
  5. Response Diagnostics stage
In addition, the pipeline must:
  • Use the edismax query parser (defType=edismax)
  • Preserve the following query parameters: tags, lw.rules.simulate, lw.app.emStatus, context, lw.tagger.debug, lw.rules.debug, lw.em.staging
  • Preserve required response fields: response.docs, response.numFound, fusion.tagger, fusion.applicable_rules, fusion.applicable_stages, response.facet_counts, responseHeader.params

Feature-specific checks

Targeted document lookup

  • The Fusion app and query profile must have the same name.
  • The query profile must support q=**:** and standard fq parameters.
  • Avoid using grouping, collapse/expand, or custom logic that may interfere with standard filter behavior.

Field value suggestions

  • The Solr collection must match the Fusion app name.
  • The collection must support the /terms request handler with standard parameters.
  • Suggestions will fail if /terms is missing or misconfigured.

Rewrites and rules interaction

  • If the Text Tagger stage appears before the Apply Rules stage, rewrites apply first.
  • If the Apply Rules stage appears before the Text Tagger stage, only the original terms are used for rule evaluation.
  • Rules must target the rewritten query term, not the original term.

Grouping via collapse/expand

  • The query pipeline must set an fq with the collapse field specified, indicating what field identifies members of a group. For example, set fq={!collapse field=product_id_s} when expand=true is passed as a query param.
  • Set the following query parameters:
    expand=true
    expand.rows=5

  • Relevant response fields include the following:
    expanded
    response.docs


Query Workbench debugging tips

  • Use the correct query profile and associated pipeline.
  • Set the following query parameters:
    lw.rules.debug=1
    lw.tagger.debug=1
    lw.em.staging=1=<FUSION_APP_NAME>_query_rewrite_staging_em
    lw.app.emStatus=CONNECTED
    queryProfileID=<ID>
    tags=<comma-separated values>
    lw.rules.target_segment=<segment>

  • Use View As: JSON to verify fusion.applicable_rules and the final query string.
  • Use custom JavaScript stages to inspect ctx or log intermediate values.

Known configuration issues

  • Hardcoded tags in pipelines may prevent rules from matching if users forget to apply corresponding tags in the Editor.
  • Query pipelines that use grouping may break document targeting. Only collapse/expand-based grouping is supported. Grouping via Solr group params or blockjoin query parser is not supported.
  • If a boost stage and a rule both adjust relevancy, only one may take effect, depending on rule priority and creation date.
