The Document Clustering job uses an unsupervised machine learning algorithm to group documents into clusters based on similarities in their content. You can enable more efficient document exploration by using these clusters as facets, high-level summaries or themes, or to recommend other documents from the same cluster. The job can automatically group similar documents in all kinds of content, such as clinical trials, legal documents, book reviews, blogs, scientific papers, and products.

Input

Output

The Document Clustering job is an end-to-end job that includes the following:
  • Document preprocessing
  • Separating out extremely lengthy documents and outliers (de-noise)
  • Automatic selection of the number of clusters
  • Extracting cluster keyword labels
You can choose between multiple clustering and featurization methods to find the best combination of methods.
LucidAcademyLucidworks offers free training to help you get started.The Quick Learning for Configuring Fusion’s Document Clustering Job focuses on how to configure parameters for the Document Clustering Job in the Fusion UI:
Configuring Fusion’s Document Clustering JobPlay Button
Visit the LucidAcademy to see the full training catalog.
LucidAcademyLucidworks offers free training to help you get started.The Course for Document Clustering focuses on document clustering methods and job configuration:
Document ClusteringPlay Button
Visit the LucidAcademy to see the full training catalog.

​
Cluster labels and frequent terms

Cluster labels are the terms that best represent the documents in a given cluster. They are typically words that can be found in the documents closest to the cluster centroid, so the dist_to_center field can be used to sort documents by similarity to the cluster_label field. Frequent terms are the terms that appear most frequently in documents in a given cluster. Different clusters may have overlapping frequent terms. Some of the frequent terms may also appear in the cluster label.

​
Configuration tips

The minimum required fields to configure are straightforward:
  • Training Collection
  • Output Collection
  • Field to Vectorize
When you first create a new Document Clustering job, set the Training Collection to point to a special collection that contains a sample set of documents. Set the Output Collection to a new, empty collection. That way, you can test the job quickly over a smaller input collection and you can clear the output collection after each test.
When you create your sample collection and your test output collection, uncheck Enable Signals to prevent secondary collections from being created.
When you are satisfied with the results of the job, set both the Training Collection and the Output Collection to your primary collection. It may take some time for the job to run over your entire primary collection. At the end, the new clustering fields are added to your existing searchable content. The sections below discuss additional ways to tune your configuration for the best results.

​
Use stopwords

The quality of your cluster labels depends on the quality of your stopwords. Managed Fusion comes with a very basic stopword list, but there may be other words in your corpus that you want to remove. If you see terms in your cluster labels that your do not want, add them to your stopwords and then re-run the job.

​
Scale your Spark resources

Make sure that you have enough resources in Spark to run the job, especially if you have many documents or your documents are long. If Spark doesn’t have enough memory, you may see out-of-memory errors in the Job History tab. If there are obstacles to scalability, you can index a subset of the text from each document then run the job on this downsized version of the documents. The algorithm does not need all of the text to generate meaningful clusters. Stopword removal also decreases the document size significantly.

​
Select the clustering method

The job provides these clustering methods:
  • Hierarchical Bisecting Kmeans (“hierarchical”)
    The default choice is “hierarchical,” which is a mixed method between Kmeans and hierarchical clustering. It can tackle the problem of uneven cluster sizes produced by standard Kmeans, and is more robust regarding initialization. In addition, it runs much faster than the standard hierarchical-clustering method, and has fewer problems dealing with overlapping topic documents.
  • Standard Kmeans (“kmeans”)
    For use cases such as novel and review clustering, several words can express similar meanings. In that case, Kmeans can perform well in combination with the Word2Vec featurization method described below. This method is also helpful when you have a corpus with a large vocabulary. Kmeans also works well when clusters are “convex”, meaning that they are regularly shaped.
There are two ways to configure the number of clusters:
  • Setting Number Of Clusters speeds up the processing time, but finding the best single value can be difficult unless you know exactly how many clusters are in the dataset.
  • Setting Minimum Possible Number Of Clusters and Maximum Possible Number Of Clusters) allows Managed Fusion to test up to 20 different values within the configured range to find the best number of clusters for your dataset based on metrics like how far each datapoint is from its associated cluster center. This optimizes the algorithm to detect true groups of similar documents and thus create better-quality clusters.
    For example, if kMin=2 and kMax=100, then the job searches through 2, 7, 12, …, 100 with a step size of 5. A large kMax can increase the running time. The algorithm incurs a penalty if k is unnecessarily large. You can use the parameter kDiscount to reduce this penalty and use a larger k-chosen. However, if kMax is small (for example, 10 or less), then not using a discount (kDiscount=1) is recommended.

​
Select the featurization method

The job provides two text-vectorization methods:
  • TFIDF You can trim out noisy terms for TFIDF by specifying the Min Doc Support and Max Doc Support parameters (minimum and maximum number of documents that contain the term).
    If you are using the hierarchical clustering method, then you should apply the TFIDF featurization method; it can provide better-detailed clusters for use cases like clustering email or product descriptions.
  • Word2Vec
    Word2Vec can reduce dimensions and extract contextual information by putting co-occurring words in the same subspace. However, it can also lose some detailed information by abstraction. If you assign Word2Vec Dimension an integer greater than 0, then Managed Fusion chooses the Word2Vec method over TFIDF.
    If you are using the standard kmeans clustering method, then you should enable the Word2Vec featurization method.
    For a large corpus dataset with a big vocabulary, Word2Vec is preferred to help deal with the dimensionality.

​
Configure de-noise parameters

The job provides three layers of protection from the impact of noisy documents:
  • In the analyzerConfig parameter, you can specify stopword deletion, stemming, short token treatment, and regular expressions. The analyzerConfig is used in the featurization step.
  • You can add an optional phase to separate out documents that are extremely long or short (as measured by the number of tokens). Extremely short or long documents can contaminate the clustering process. Documents with a length between Length Threshold for Short Doc and Length Threshold for Long Doc are kept for clustering.
  • The job performs outlier detection using the Kmeans method. Managed Fusion groups documents into Number of Outlier Groups, then trims out clusters with a size less than Outlier Cutoff as outliers.
    Outliers are documents that are too distant from the nearest centroid or nearest neighbors. These distant outliers are grouped into outlier clusters and labeled as outlier_group0, outlier_group1 …​ outlier_groupN, where N is the value of Number of Outlier Groups.

​
Configure cluster labelling

The configuration parameter Number Of Keywords For Each Cluster determines the number of keywords to pick to describe each cluster. Test different values until you find that the cluster labels give an accurate depiction of the data contained within a given cluster.

​
Evaluating and tuning the results

When the job has finished:
  1. Navigate to the output collection.
  2. Open the Query Workbench.
  3. Click Add a Field Facet and select cluster_label.
    The cluster_label field contains the five terms that best define the center of each cluster.
  4. Click Add a Field Facet again and select freq_terms.
    The freq_terms field contains the five terms that appear most often in each cluster.
    In many cases, the frequent terms in a cluster are also among those that best define it.
The dist_to_center field can be used to sort documents by similarity to their cluster labels.
  1. Explore the facets to determine whether the clusters are useful.
    • Be sure to examine the long_doc cluster and any outlier_group<n> clusters. If no outliers are detected, consider increasing outlierK or outlierThreshold.
    • If you see terms that you do not want in your cluster labels, add them to your stopwords.
    • To tune the granularity of your clusters, adjust the values of Min Possible Number of Clusters and Max Possible Number of Clusters. Increasing these values will break up some of the bigger groups into smaller ones. Decreasing the values can consolidate smaller groups into larger ones. Experiment until you find the level of granularity that produces the most meaningful clusters.
    • If the clusters are very uneven, such as when most documents are in one large cluster:
      • Try increasing the outlier cutoff (some outlier groups are being labeled as clusters).
      • Try increasing k (you have many clusters combined into one).
    • If you have many outlier groups, but only a few docs per outlier group, try increasing the outlier cutoff to avoid saturating your number of outlier groups before all outliers have been removed.
    • If the corpus is large and the clustering job is taking too long:
      • Use Kmeans and Word2Vec (Kmeans does not usually do well with TF*IDF).
      • Use an exact k value (Number Of Clusters) instead of a range (Min Possible Number of Clusters and Max Possible Number of Clusters).
    • If the clustering job completes successfully according to logs, but is not writing data to Solr, check the schema specs on output fields. Solr strings have a maximum length that Spark strings do not. Use text type if your outputs are very long.
    this problem will only appear if reading from and writing to different collections.
  2. Re-run the job and examine the facets again to see whether the results are more useful.

​
Back up your primary collection

Before running this job over your primary collection, make sure you have a backup of the original content. This can come in handy if you change your mind about the results and want to overwrite the document clustering fields.

​
