SharePoint Online V1 Optimized

​

Decide what you need to crawl

• An entire SharePoint Web application (all site collections in a specific SharePoint URL).
• A subset of SharePoint site collections.
• A specific sub-site, list, or list item.

​

How to crawl an entire SharePoint Web application

1. Leave the Limit Documents > Fetch all site collections option checked (as it is by default).
2. Specify the Web application URL as a site. For example: https://lucidworks.sharepoint.local/

​

How to crawl a subset of SharePoint site collections

1. Uncheck the Limit Documents > Fetch all site collections option.
2. Specify a “Start Link” for each site collection that you want to crawl. Examples: https://lucidworks.sharepoint.local/sites/site1, https://lucidworks.sharepoint.local/sites/site2, https://lucidworks.sharepoint.local/sites/site3

​

How to crawl a specific sub-site, list, or list item:

1. Uncheck the Limit Documents > Fetch all site collections option.
2. Specify a “Start Link” for each site collection that contains the item you want to fetch.
3. Specify a non-wildcard Inclusive Regular Expression for each parent. For example, if you want to crawl https://lucidworks.sharepoint.local/sites/mysitecol/myparentsite/somesite then you must include inclusive regexes for all parents along the way:
   Copy

   https\:\/\/lucidworks\.sharepoint\.local\/sites\/mysitecol
   https\:\/\/lucidworks\.sharepoint\.local\/sites\/mysitecol\/myparentsite
   https\:\/\/lucidworks\.sharepoint\.local\/sites\/mysitecol\/somesite
   https\:\/\/lucidworks\.sharepoint\.local\/sites\/mysitecol\/somesite\/.*


   If you exclude a parent item of the site, the connector will not crawl the site because it will never spider down to it during the crawl process.

​

Choose an authentication method

1. SharePoint service account - This method is the equivalent of logging in under a user account. If the account is not an admin user, however, you need to grant the account access to each site collection you want to crawl. Required parameters:
   • Username
   • Password
   • Tenant
2. App-only authentication using Azure AD with a private key - Using this method requires the application key to have “Full Control” permissions. Otherwise, security authorization errors occur while crawling. This is the most commonly used method. Required parameters:
   • Client ID
   • PFX key in Base64 format
   • PFX key password
   • Tenant
   Set the following permission to crawl SharePoint:
   1. Click API permissions in the left panel.
   2. Navigate to Application permissions > Sites.
   3. Select the Sites.FullControl.All check box.
   4. Click Add permissions to save the changes.
   If the Sites.FullControl.All option is not selected, 403 errors are generated while crawling.
   For detailed information about configuration, see Granting access via Azure AD App-Only.
3. App-only authentication using Azure AD with OAuth - Using this method requires the application key to have “Full Control” permissions. Otherwise, security authorization errors occur while crawling. This is the least commonly used method. Required parameters:
   • Client ID
   • Client secret
   • Tenant
   You have two options here:
   • Set up a crawl account with only as much permission as it needs.
   This approach has the security advantage of providing minimal access to Fusion. However, the crawl account cannot retrieve the list of site collections behind a Web application URL. It cannot access the SharePoint Tenant Admin API to list all the site collections on your tenant. If you use this authentication method, you must enter each site collection to crawl in Start Links.
   • Provide administrative access to crawl
   Grant the App the following permission to crawl SharePoint:
   Copy

   <AppPermissionRequests AllowAppOnlyPolicy="true">
    <AppPermissionRequest Scope="http://sharepoint/content/tenant" Right="FullControl" />
   </AppPermissionRequests>


   If the Right field is not set to FullControl, 403 errors are generated while crawling.

​

How to set up a crawl account

​

1. Create a service account and license the account (if needed)

• If you are using an on-premise active directory synced to SharePoint Online, then you need to create an Active Directory account, and license the Active Directory account on SharePoint Online.
• If you are using SharePoint Online user accounts, add a user as the “Lucidworks Fusion service account”.
  Add the user as “User (no administrator access)”.

​

2. Create a Lucidworks Fusion crawl permission

1. Navigate to Azure Active Directory > Conditional Access > Policies.
2. Click New Policy.
3. Click New permission level. In this example, the permission level is named “LW Fusion”.
4. Grant the following permissions:
   • View Items - View items in lists and documents in document libraries.
   • Open Items - View the source of documents with server-side file handlers.
   • View Versions - View past versions of a list item or document.
   • View Application Pages - View forms, views, and application pages. Enumerate lists.
   Site Permissions
   • Browse Directories - Enumerate files and folders in a Web site using SharePoint Designer and Web DAV interfaces.
   • View Pages - View pages in a Web site.
   • Enumerate Permissions - Enumerate permissions on the Web site, list, folder, document, or list item.
   • Browse User Information - View information about users of the Web site.
   • Use Remote Interfaces - Use SOAP, Web DAV, the Client Object Model or SharePoint Designer interfaces to access the Web site.
   • Open - Allows users to open a Web site, list, or folder in order to access items inside that container.

​

3. Grant user permission to the user policy

1. Navigate to Site settings > Site permissions > Advanced Permissions Settings > Grant permissions.
2. Enter the desired user.
3. Grant Read and your custom Fusion permissions, “LW Fusion”, for this user:

​

Limitations of a crawling SharePoint Online with a non-administrative account

• list them in the Start Links explicitly, or
• provide a SharePoint administrator account when crawling SharePoint Online.

​

How to provide admin access to crawl

• You can create a service account with admin access (not recommended).
• You can create an app-only authentication key. If you choose this approach, you can either use OAuth or the JWT private key option.
